Landing gear – 3 Legs

Description

Front Leg

• Size leg: models from 10 to 18 kg.
• Connection to the retract: 12 mm diameter.

NOTE:

• Use Loctite 242 thread locker for the M8 wheel connection. * Every 50 uses add a dense grease inside the cylinder.
• Connection to the shaft axis : M8. * Weight without wheel: 122 grams.

Rear Leg

• Size leg: models from 10 to 18 kg.
• Connection to the retract = 12 mm diameter.
• Connection to Shaft axis: M8.

NOTE:

• Use Loctite 242 thread locker for the M8 wheel connection * Every 50 uses add a dense grease inside the cylinder
• Reversible right / left mounting. * Weight without wheel: 93 grams.
