Description
Tron 5.8 HERITAGE. Helicopter Kit, without blades and electronics.
The Tron 5.8 Heritage RC Helicopter is a high quality 580 class electric heli that provides an extensive feature list, flight envelope, and simplicity in design. The 5.8 features many design elements that are shared within the family of helicopters from the 5.5, NiTron, and 7.0. Features such as the octo-boom that is free of boom supports, elegant and simple battery tray system, optimized servo and rotor head geometry, and simple wiring for your electronic components.
The 5.8 Heritage delivers newly found features that are standard in the kits. A boost in aesthetics is delivered thanks to the additional Fusion design, that adds high visibility color matched stickers to the side frames, and tail fin. In addition to that, canopy installation and removal couldn’t be any easier thanks to the supersonic rear style canopy mounts. In addition, two color styles are available – Orange/White/Black, and Grey/Yellow/Black. Pick your style above.
The 5.8 is purpose built to deliver incredible performance for pilots who are looking to equip the heli with either 580mm or 610mm main blades. All up weight of the model (airframe only) comes in around 1530 grams (~3.4lbs). Due to the lightweight design, and wide acceptance of 6s through 12s power systems, the performance and feel is up to your preference as a pilot and components that are installed. Pair this with the ability to use either full size or mini size servos for the rotor head, you can further enhance the performance through the wide choice of components.
Features at a Glance:
- Optimized servo and rotorhead geometry
- Accepts full size & mini size cyclic servos
- Adjustable dampened gyro mounting tray
- Bearing supported motor pinion system
- Octo boom without boom supports
- High visibility canopy & fusion style decals
- Supersonic rear canopy mounts
Specifications:
- Main Blade Length: 580-610mm
- Tail Blade Length: 85-96mm
- Motor Drive Gear: 16T
- Main Drive Gear: 137T
- Autorotation Tail Drive Gear: 80T
- Tail Drive Gear: 19T
- Drive Gear Ratio: 8.563:1:4.21
- Weight (Airframe Only): 1530g
Needed to Complete:
- (1) 2.4GHz Transmitter & Receiver (6-channel or more, helicopter system)
- (1) 580-610mm Main Blades
- (1) 85-96mm Tail Blades
- (1) 4020-4225 Size Brushless Motor (kV dependent on battery choice)
- (3) Full size or Mini cyclic servos
- (1) Full size tail servo
- (1) 3-Axis Flybarless System
- (1) ESC (120A+)
- (1+) Batteries:
- 6s: 5000 – 5500mAh
- 7s: 4500 – 5500mAh
- 8s: 4000 – 5000mAh
- 12s: 3000-3500mAh
- Compatible charger
- Pitch gauge
- Various tools, lubes & greases for setup and assembly
