GAUI X7 FZ Basic Kit

Description

X7 FZ Basic Kit

X7 FZ Battery Dimensions:

• Max Length: 325mm
• Max Height: 62mm
• Max Width: 65mm

Content:

X7 FZ Basic Kit x 1 set
X7 10T x 1 pc

Specifications:

Overall Length: 1340 mm
Main Rotor Diameter: 1610mm
Main rotor blades: 720mm
Overall Height: 383mm
Overall Width: 200mm
Tail Blade Length: 105mm
Tail Rotor Diameter: 290mm
Flying duration: 4~5 minutes(3D flight )

Required for operation

Transmitter(6-channel or more,helicopter system)
Receiver(6-channel or more)
Standard size CCPM servos  x  3pcs (>15kg torque)
Standard size tail servo x 1pc
3-Axis Gyro x 1pc
Battery :6S1P (22.2V/4200mAh ~5500 mAh) x 2pcs
450~500 KV Blushless motor x 1pc (Motor shaft length ~46mm, Ø6mm)
12S 120~160A ESC x 1pc
CF Main Blades(700mm) x 1 set
CF Tail Rotor Blades(105mm) x 1 set
